Surface Science Related System : Hight Temperature Wettability Evaluation System by Contact Angle at the Solid-Liquied Interface WET-1200
A compact, low-cost high temperature wettability tester / contact angle measurement system
It is capable of measuring via extruded liquid drop method (optional) as well as static drop method. (Analysis / calculation system via PC is optional.)
Features
• Clean and quick heating & cooling due to Infrared Gold Image furnace used as a heating furnace
• Atmosphere can be selected freely among vacuum, inert gas and air etc.
• Extruded liquid drop method is available as optional
• Capable of measuring advancing and receding contact angles
Applications
• Research and development, quality management of welding, brazing and soldering
• Research and development of casting alloys and mold materials
• Liquid phase sintering research
• Wettability test of molten glass and sealing metal
Specifications
|
Temperature range |
Static drop method (Standard) |
～ 1500 °C |
|
Extruded liquid drop method (Optional) |
～ 1200 °C |
|
|
Atmosphere |
Vacuum, Inert gas, Air |
|
|
Substrate size |
φ 10 × t 2 (mm) |
|
|
Contact angle measurement |
Outline observation by static drop method (Standard) Image analysis / contact angle calculation system by PC (option) |
|
