Infrared Lamp Heating System : SSA series
Simplified system with Infrared Gold Image Furnace and a quartz chamber
A low-cost heating system composed from a quartz chamber that includes an Infrared Gold Image Furnace and sample holder.
Features
• Quartz chamber is selectable from gas flow type or vacuum type. (Gas flow type is standard.)
• Gas flow type and vacuum type can be integrated as option.
• Simple input of temperature recipe into computer connected with USB
• Display temperature data on the PC monitor during heating
Specifications
|
Model |
SSA-E45P |
SSA-E410P |
SSA-P610CP |
|
Heating Method |
Focused light cylindrical heating |
Focused light cylindrical heating |
Parallel light cylindrical heating |
|
Temperature Range |
RT ～ 1400 °C |
RT ～ 1200 °C |
|
|
Heating zone |
φ 15 × L 50 (mm) |
φ 15 × L 100 (mm) |
φ 50 × L 100 (mm) |
|
Soaking zone |
φ 10 × L 40 (mm) |
φ 10 × L 80 (mm) |
φ 40 × L 80 (mm) |
|
Heating chamber |
Quartz chamber (φ 30 mm) for gas flow |
Quartz chamber (φ 98 mm) for gas flow |
|
|
Sample holder |
Quartz holder with boat shape |
Quartz holder with boat shape |
Quartz holder for 2-inch wafer |
|
Thermocouple |
JIS R-type |
||
|
Temperature controller |
TPC5000-32-1 |
TPC5000-62-1 |
|
*Heating temperature changes according to the heated sample’s infrared reflectance, absorption, heat capacity, and material.
