Infrared Lamp Heating System : MIRO series

Heating up to 1800°C in just 1 min. For ultra-high temperature vacuum heat treatment
MIRO series is a compact spot focused Gold Image Furnace which enables to heat up to 1800°C with extremely high reflection efficiency in combination with single or double type chambers.

Features
• Compact, low-cost ultra-high temperature heating furnace
• In combination with single type or double type chambers, it enables to heat in atmosphere such as vacuums and inert gases (MR-39H/S, MR-39H/D combination)
• It is available to observe the samples during heating.
• It enables to heat up to 1800°C at 100V and 2kW (MR-39H/D model)
• It is available to easily input outer signal or temperature program setting from your PC and display the temperature data during heating on the monitor.

Applications
• Ultra-high temperature vacuum heating treatment
• Crystal growth testing (Zone melting)
• Ultra-high temperature heating test for a small sample
• Local heating thermal shock test
• Thermal cycle testing
• Thermal analysis
• For a generating gas pyrolyzer
• Experimental furnace under microgravity

Specifications

*Please use MR-H5500 designed for MIRO series as the program temperature controller.
